NDAA-Aligned FPV Systems for Defense, Security and ISR

Our Mission

Carbontronics designs and manufactures mission-ready FPV and small UAS platforms engineered for speed, reliability, and operational deployment.

Our systems integrate video, RF, flight control, and onboard compute into modular architectures supporting ISR, autonomy, and AI-enabled capabilities.

NDAA Compliant Architecture

Submitted for Blue UAS evaluation

Submitted for Blue UAS evaluation

Designed around NDAA-compliant components and a secure supply chain.

Submitted for Blue UAS evaluation

Submitted for Blue UAS evaluation

Submitted for Blue UAS evaluation

Monarch platform formally submitted for evaluation under the Blue UAS program.

US-based design and manufacturing

Submitted for Blue UAS evaluation

US-based design and manufacturing

Designed and assembled in the United States with scalable domestic production capability.

110+ MPH

15-Mile Operational Range

US-based design and manufacturing

Capable of 10km in under 5 minutes for a quick response time. Safely sustain 100mph for 1 mile

Modular payloads

15-Mile Operational Range

15-Mile Operational Range

Supports ISR sensors, RF payloads, broadcast systems, and custom integrations.

15-Mile Operational Range

15-Mile Operational Range

15-Mile Operational Range

Verified with 2 kg payload under controlled flight testing conditions.

Flagship UAS - NDAA compliant

Spec sheet

Monarch

currently supported in 2 versions. A cinema ISR version, and a terminal guidance defense version

Aircraft type

FPV Quad

Max Speed

113 mph

with full payload

Flight time

10-20 minutes

payload and speed dependent

Range

15 miles

Weight empty

3.46lbs

Payload Capacity

0-5lbs

carry cameras, gimbals, lights, lasers, kinetic payloads. Modular payload system makes it easy to integrate any payload.

Max take off weight

12 lbs

Propulsion

12s

50v system provides clean power distribution and reliable electronics.

Control link

Crossfire

easily configurable to custom options

Video Transmission

Analog/hd zero

currently supported in analog and hd zero, however configurable to custom solutions such as licensed bands.

Navigation

GNSS

return to home available.

Compliance

NDAA compliant core components

software

Future-upgradable system

Flight controller software

Betaflight/inav/aardupilot

user configurable

Terminal guidance

custom

Capable of running  custom software via user configurable onboard computer

aircraft is rapidly iterating and new features are being tested and will be added to official spec sheet soon.

Purchase NDAA compliant cinema uas versions through our authorized retailer

compliant aero

Contact Us

GOVERNMENT INQUIRIES

Carbontronics is actively engaging with U.S. Department of Defense organizations to evaluate the Monarch platform for operational use. The Monarch platform has been submitted for Blue UAS review.

The Monarch platform is designed around NDAA-compliant components and domestic manufacturing to support U.S. government requirements.

Government organizations interested in evaluating the Monarch platform are encouraged to contact our Government Programs team.
